12.3.1. Modelos with flat burrs
Position the regulator collar (
) leaving about 45º between the grind point lock
) and regulator limit stop (Fig. 13). In that position, tighten the regulator
screw (
) on the upper burr carrier and with a T20 Torx screwdriver, as Fig. 10.
(
For the models with the micrometric Parallel system, first make sure that the grind
point lock screw (
) is lined up with the locking foot. This will ensure that the lock
screw and locking foot move in conjunction with one another, and that the locking
mechanism works properly (Fig. 11).
23
K06307 | v. 22/09/2014 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS
