Compak E6 OD Instruction Manual page 13

* It is recommended that the motor be running when adjusting to finer grind setting.
This helps to avoid jamming the burrs, which can occur when coffee beans are in the
grind chamber, and the grind regulator is adjusted towards fine.
8.3.2. Stepped grind adjustment (optional)
In the stepped adjustment versions, the positions on the grind regulator are limited
by "steps" that are defined by the hole and pin points (Fig. 6).
The instructions detailed in section 8.3.1. on adjusting the regulator should be
followed, while at the same time, pulling the brake post (
locking action of the post.
NOTE: If the output is very slow, it could mean that the coffee is being ground too
fine. If the output is very fast, it could mean that the coffee is being ground too coarse.
A perfect espresso grind is found when the grind point gives an infusion of 25 ml of
coffee in 25 seconds using 7 grams of ground coffee.
K06307 | v. 22/09/2014 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS
) (Fig. 6) up to release the
11
