3. Technical Parameters

Supported Protocols

LAN interface – IPv4, ARP, TCP, UDP, DHCP
Device configuration – HTTP/HTTPS
Call signalling – SIP 2.0 (UDP)
Audio data transmission – RTP (G.711, G.729)
Audio streaming – RTSP
Time synchronisation – SNTP
Auto provisioning – TFTP
E-mail sending – SMTP
Power Supply
External power supply – Typ. 12V DC (9 – 36V DC), up to 1.5A
PoE – 802.3af (Class 0 – up to 12.95W)
Power consumption – 2W at relax
LAN Interface
LAN interface count – 2 (LAN1 and LAN2)
PoE – 802.3af on LAN1 only
Parameters – 10/100BASE-TX with Auto-MDIX, RJ-45
Recommended cabling – Cat-5e or higher
Video Interface
Video input count – 2 (IN1, IN2)
Video input format – PAL or NTSC composite signal
Camera power supply – 12V, max 500mA (+12V, VGND)
®
