Miller Robotic Interface II Owner's Manual page 14

Controls welding power source for robotic welding applications
Hide thumbs Also See for Robotic Interface II:
Table of Contents

Advertisement

WARNING
BUILDUP OF SHIELDING GAS can harm health or kill.
Shut off shielding gas supply when not in use.
Install & Connect
Interface Into
Personal Safety
Welding System
Equipment
Adjust Weld
Parameters
As Needed
Figure 4-5. Sequence Of Gas Metal Arc (GMAW), Gas Metal Arc - Pulse (GMAW-P),
Figure 4-6. Setting Switches On 450 Ampere Inverter Model Welding Power Source
OM-172 324 Page 8
Figure 4-4. Shielding Gas
Put On
Turn On
Welding System
Equipment
Begin
Welding
And Flux Cored Arc Welding (FCAW)
2
1
Turn On Shielding
Set All Controls
Gas
Program Selection
Set switches as shown for all
welding processes when using
this interface unit.
1
Shielding Gas Cylinder
2
Valve
Open valve on cylinder just before
welding.
Close valve on cylinder when fin-
ished welding.
sb5.1* 6/92 – S-0621-C
Perform Test
And Verify
Weld
Ref. ST-150 171-C / Ref. SC-154 197
warn1.1 9/91
ssb6.1* 9/92
