V DC and AC (1)
Resolution
Impedance
Accuracy
Permitted
overload
(1) Use on frequency : 40 Hz to 500 Hz
Min. threshold on V AC : 25 mV from 40 Hz to 100 Hz and 300 mV from 100 Hz to 500 Hz
Min. threshold on V DC : 10 mV
Never test a resistance on a live circuit
Connect the leads to the multimeter and to the circuit or the
component to be tested.
Place the selector switch on the ohmmeter function Ω
Automatic range selection : read the measured value
Freeze the value, if necessary, by pressing the HOLD button.
Ω Ω Ω Ω Ω
Resolution
Accuracy
Voltage on
open circuit
Protection
Place the selector switch on the
Continuous audible beep emitted for a resistance R ≤ 700 Ω
Never test a diode on a live circuit
Connect the leads to the multimeter and to the terminals of the
component to be tested. With this function, it is possible to test,
besides classic diodes, LED's or any other semiconductor in which
the junction corresponds to a direct voltage less than 3 V.
200 mV
0.1 mV
on DC : ± 1 % reading ± 1 count
on AC : ± 1 % reading ± 5 counts
4 - RESISTANCE
200 Ω
0.1 Ω
± 1.5 % rdg
± 5 counts
5 - CONTINUITY BEEPER
6 - DIODE TEST
2 V
20 V
1 mV
10 mV
3 MΩ
600 V rms and 900 V peak
2 kΩ
20 kΩ
1 Ω
10 Ω
± 1.5 % rdg
± 3 counts
≤ 0.5 V
500 V rms and 750 V peak
function
5
200 V
100 mV
200 kΩ
2 MΩ 20 MΩ
100 Ω
1 kΩ
± 3 % rdg ± 5 counts
600 V
1 V
10 kΩ
