Summary of Contents for AEMC SL206
- Page 1 AC/DC Current Probe Model SL206 USER MANUAL GlobalTestSupply www. .com Quality AEMC Products Online at: sales@GlobalTestSupply.com...
-
Page 2: Statement Of Compliance
Serial #: Catalog #: 1201.45 Model #: SL206 Please fill in the appropriate date as indicated: Date Received: Date Calibration Due: ® Chauvin Arnoux , Inc. ® d.b.a AEMC Instruments www.aemc.com GlobalTestSupply www. .com Quality AEMC Products Online at: sales@GlobalTestSupply.com... -
Page 3: Limited Warranty
Limited Warranty The AC/DC Current Probe Model SL206 is warranted to the owner for a period of 1 year from the date of original purchase against defects in ® manufacture. This limited warranty is given by AEMC Instruments, not by the distributor from whom it was purchased. -
Page 4: Table Of Contents
AC/DC Current Probe Model SL206 Table of Contents Warning ..................... 3 Limited Warranty ..................3 Warranty Repairs ..................3 International Electrical Symbols ..............3 Definition of Measurement Categories ............4 Receiving Your Shipment ................4 Packaging ....................4 Compatibility ....................4 Description .................... -
Page 5: Warning
AC/DC Current Probe Model SL206 Warning These safety warnings are provided to ensure the safety of personnel and proper operation of the instrument. Connect the probe to the oscilloscope or voltage measuring instrument before clamping the probe around a conductor. -
Page 6: Definition Of Measurement Categories
Packaging The AC/DC Current Probe Model SL206 (Cat. #1201.45) is shipped with one 9V battery (not installed) and this user manual. Compatibility The AC/DC Current Probe Model SL206 is compatible with any DMM,... -
Page 7: Description
AC/DC Current Probe Model SL206 Description AC/DC Current Probe Model SL206 measures low DC or AC from 10mA to 80A , 60A . This battery-powered clamp-on probe may be used with digital multimeters, voltmeters, or other voltage-measuring instruments. The probe jaws clamp around the conductor under test, allowing current measurements without breaking the circuit. -
Page 8: Specifications
AC/DC Current Probe Model SL206 Specifications ELECTRICAL SPECIFICATIONS Current Range: 10mA to 80A ; 50mA to 60A Output Signal: 1mV/mA and 10mV/A AC/DC Accuracy and Phase Shift*: Range 1mV/mA (1V/A) 10mV/A 10mA to 2A Current Range 50mA to 80A 10mA to 1.5A... -
Page 9: Mechanical Specifications
AC/DC Current Probe Model SL206 MECHANICAL SPECIFICATIONS Operating Temperature: 32° to 122°F (0° to 50°C) Storage Temperature: -22° to 176°F (-30° to 80°C) Temperature Influence: < 0.2% per °C Operating Relative Humidity: 10° to 30°C: 85% ± 5% RH (without condensation) 40°... -
Page 10: Safety Specifications
AC/DC Current Probe Model SL206 Weight: 11.6 oz (330g) with battery Color: Dark gray Output: Double insulated 5 ft (1.5m) lead with safety banana plugs SAFETY SPECIFICATIONS Electrical: 600V Category III, Pollution: 2 Double insulation or reinforced insulation between primary or secondary... -
Page 11: Frequency Response Curves (Typical)
AC/DC Current Probe Model SL206 Frequency Response Curves (Typical) 1 mV/mA 10 mV/A 1000 10000 GlobalTestSupply www. .com Quality AEMC Products Online at: sales@GlobalTestSupply.com - 9 -... -
Page 12: Operation
Connect the current probe to the multimeter or other instrument. Be sure to observe the polarities: red = positive terminal, black = common terminal. The Current Probe Model SL206 has a dual output, DC V output in DC and AC V output in AC. The “1V/A” range has an output signal of 1mV/mA AC/DC with an output of 2 volts representing 2 amps present in the conductor being measured. -
Page 13: Current Measurement
AC/DC Current Probe Model SL206 Current Measurement Select the appropriate range on your multimeter. Zero the probe in DC and in DC coupled AC measurements. Observe the output polarities for DC measurement. Clamp the probe on the conductor to be measured and read the current flowing directly on your meter. -
Page 14: Repair And Calibration
AC/DC Current Probe Model SL206 Repair and Calibration To ensure that your instrument meets factory specifications, we recommend that it be submitted to our factory Service Center at one-year intervals for recalibration, or as required by other standards or internal procedures. - Page 15 GlobalTestSupply www. .com Quality AEMC Products Online at: sales@GlobalTestSupply.com...
- Page 16 ® ® Chauvin Arnoux , Inc. d.b.a AEMC Instruments 15 Faraday Drive • Dover, NH 03820 www.aemc.com GlobalTestSupply www. .com Quality AEMC Products Online at: sales@GlobalTestSupply.com 99-MAN 100029 v12 07/11...
