LIQUID CRYSTAL DISPLAY
2000 measurement counts (height of digits 0.65")
Rate : 2 measurements / second
: low battery indication
Overload indication : the 1 on the left flashes
CONTROL BUTTONS
HOLD
Hold button freezes the measurement on display
RANGE
Range selection : Press the range button to change from automatic
mode to manual mode. The automatic mode is selected when the
instrument is switched on.
Note : The 200 mV AC range is only accessible on manual.
Press 3 times on the RANGE button to access this range.
FUNCTION SELECTOR SWITCH
OFF
Off position
V
DC and AC voltages up to 600 V
Continuity sound test for a resistance R < 700 Ω
Ω Ω Ω Ω Ω
Resistances up to 20 MΩ.
TERMINALS
Ø 4 mm safety terminals
COM : common, black
+
: red
Connect the leads to the multimeter and connect it in parallel to
the circuit to be tested.
Place the selector switch on the voltmeter function V. Automatic
selection of the range and the DC or AC mode; read the value
measured.
Freeze the value, if necessary, by pressing the HOLD button.

2 - DESCRIPTION

3 - DC AND AC VOLTAGE
