Microscan Quadrus MINI Imager User Manual page 43

Defaulting
When you select Default Current Menu Settings or Default all ESP Settings, you are
only defaulting the ESP settings.
Advanced Options
Send Current View
This is the same as Save to Reader
> Send No Save except that only the
commands in the current configuration
tree are sent.
Send Current Command
This is the same as Send Current
View, except that it saves only the
command that is currently selected.
Add/Remove Exception
After you perform a Receive Reader Settings command
option, you may see a list of serial commands. These are commands that may be in your
imager's firmware, but not included in, or different from, your current version of ESP.
You can edit these commands by double-clicking on them and changing them as needed.
It is important to note that these commands will be saved to your imager whenever you
send a Save to Reader command, or an
Also, if there is a corresponding ESP menu item, the ESP Value column for that item will
be blank following a Receive Reader Settings command.
1. From the Send/Recv button or by right-clicking in any blank section of a tree control view.
Quadrus MINI Imager User's Manual
1
and you click on the Add Exception
<A> or a <Z> command.
Using ESP
2-17
