Matchcode Serial Commands

Matchcode Type
Number of Master Symbols
New Master Pin
Enter Master Symbol Data
Request Master Symbol Data
Delete Master Symbol Data
Match Replace
Mismatch Replace
Quadrus MINI Imager User's Manual
<K223,matchcode type,sequential matching,match start
position,match length,wild card character,sequence on
No Read,sequence on mismatch>
<K224,number of master symbols>
<K225,status>
<K231,master symbol number,master symbol data>
<K231?,>[for all] or <K231?,master symbol number>
<K231,master symbol number,>
<K735,status,match replacement string>
<K736,status,mismatch replacement string>
Matchcode
9-3
