Multisymbol

Usage:
Multisymbol is commonly used in shipping applications where a shipping
symbol contains individual symbols for part number, quantity, etc. This
feature allows on trigger to pick up all the symbols.
Definition:
Multisymbol allows the user to define up to 100 symbols that can be read
in a single read cycle.
Conditions:
The following conditions apply:
• Each symbol must be different to be read, unless in Rapid Capture
• The maximum number of characters in a read cycle is 3,000 for all
• All No Read messages are posted at the end of the data string, unless
• If more than one symbol is within the field of view at the same time,
• If Matchcode Type is set to Sequential or if Trigger is set to Continuous
Number of Symbols
Definition:
Number of Symbols is the number of different symbols that can be read in
a single read cycle.
Serial Cmd:
<K222,number of
Default:
1
Options:
1 to 100
Multisymbol Separator
Usage:
Used to delimit or separate data fields with a user defined character.
Definition:
Any valid ASCII character, inserted between each symbol read when Multisymbol
is set to any number greater than 1.
Serial Cmd: <K222,number of
Default:
, (comma)
Options:
Any available ASCII character.
Important: The ASCII characters <, >, and
For <: <K222h,,3C>
For >: <K222h,,3E>
,
For : <K222h,,2C>
See ASCII Character Entry Modifier
to enter ASCII characters as hex values.
Note: If No Read messages are disabled and there are No Reads occurring, separators
will only be inserted between symbol data outputs.
Quadrus MINI Imager User's Manual
Mode, configured for "triggered capture".
symbols.
output filtering is enabled.
symbol data may not be displayed in the order of appearance.
Read 1 Output, the imager will behave as if Number of Symbols were
set to 1, regardless of the user-defined configuration.
symbols, multisymbol separator>
symbols,multisymbol
on page 3-32 for a more detailed explanation of how
separator>
,
can only be entered as hex pairs:
Read Cycle
