EZ Trax Output
Comm Port
Image Mode
Image Format
Quadrus MINI Imager User's Manual
I/O Parameters
When EZ Trax output is
enabled, the imager will attempt
to output all enabled EZ Trax
options. EZ Trax will not function
unless enabled.
Selects the communication port
that will be used to transfer
image files.
Determines which
read cycle condition
triggers image file
output.
Selects the format of the image
output file.
7-53
