10. Identify the Left Pedal (24), which is marked with an
"L." Using an adjustable wrench, firmly tighten the
Left Pedal counterclockwise into the left arm of the
Crank (21).
Tighten the Right Pedal (not shown) clockwise into
the right arm of the Crank. IMPORTANT: Tighten
both Pedals as firmly as possible. After using
the exercise cycle for one week, retighten the
Pedals. For best performance, keep the Pedals
tightened.
Adjust the strap on the Left Pedal (24) to the
desired position, and press the end of the strap
onto the tab on the Left Pedal. Adjust the strap on
the Right Pedal (not shown) in the same way.
11. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly
is completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
10
25
24
Tab
10
21
