Brs 19-Inch 2U; Removing The Chassis Cover - Bosch BRS Tower Hardware Installation Manual

26 en | Maintenance
3.2

BRS 19-inch 2U

CAUTION!
Review the warnings and precautions listed in the manual before setting up or servicing this
chassis.
3.2.1

Removing the Chassis Cover

Removing the Chassis Cover
1.
2.
3.
4.
CAUTION!
Except for short periods of time, do NOT operate the system without the cover in place. The
chassis cover must be in place to allow proper airflow and prevent overheating.
- | V1 | 2011.10
Remove the two screws on each side of the cover, which secure the cover to the chassis.
Press the release tabs to remove the cover from the locked position. Press both tabs at
the same time.
Once the top cover is released from the locked position, slide the cover toward the rear
of the chassis.
Lift the cover off the chassis.
Hardware Installation Manual
Bosch Recording Station Appliance
Bosch Security Systems
