20
en | System Overview
2.4.3
Drive Carrier LEDs
Your chassis uses SAS/SATA.
Each SAS/SATA drive carrier has two LEDs.
–
–
- | V1 | 2011.10
Power
Indicates power is being supplied to the system's power supply units. This LED
should normally be illuminated when the system is operating.
Green: Each Serial ATA drive carrier has a green LED. When illuminated, this green LED
(on the front of the SATA drive carrier) indicates drive activity. A connection to the SATA
backplane enables this LED to blink on and off when that particular drive is being
accessed.
Red: The red LED indicates a SAS/SATA drive failure. If one of the SAS/SATA drives fail,
you should be notified by your system management software.
Hardware Installation Manual
Bosch Recording Station Appliance
Bosch Security Systems
