5
FUNCTIONS FOR RECEIVE
D Scope set mode (continued)
Select the sweeping speed for the ±50 kHz span se-
lection from SLOW, MID and FAST.
Select the sweeping speed for the ±100 kHz span se-
lection from SLOW, MID and FAST.
Select the sweeping speed for the ±250 kHz span se-
lection from SLOW, MID and FAST.
Set the scope edge frequencies for fix mode scope
with below 1.6 MHz band selection.
Set the scope edge frequencies for fix mode scope
when 1.6 to 2 MHz band is selected.
Set the scope edge frequencies for fix mode scope
when 2 to 6 MHz band is selected.
Set the scope edge frequencies for fix mode scope
when 6 to 8 MHz band is selected.
• Set the frequencies within 0.030 to 1.600 MHz range
in 1 kHz steps.
Up to 500 kHz band width can be specified, so ei-
ther edge frequency will be set to the difference
between higher and lower frequencies become 5
to 500 kHz automatically while setting another
edge frequency.
• Set the frequencies within 1.600 to 2.000 MHz range
in 1 kHz steps.
• Set the frequencies within 2.000 to 6.000 MHz range
in 1 kHz steps.
Up to 500 kHz band width can be specified, so ei-
ther edge frequency will be set to the difference
between higher and lower frequencies become 5
to 500 kHz automatically while setting another
edge frequency.
• Set the frequencies within 6.000 to 8.000 MHz range
in 1 kHz steps.
Up to 500 kHz band width can be specified, so ei-
ther edge frequency will be set to the difference
between higher and lower frequencies become 5
to 500 kHz automatically while setting another
edge frequency.
5-6
