Icom IC-7800 Instruction Manual page 192

14
CONTROL COMMAND
D Command table (continued)
Cmd. Sub Cmd. Data
1A 050073 00 or 01 Send/read split lock set
050074 00 or 01 Send/read tuner auto start set
050075 00 or 01 Send/read PTT tune set
050076 00 or 01 Send/read transverter set
050077 see p. 14-10 Send/read transverter offset
050078 00 to 02 Send/read RTTY mark frequency
050079 00 to 02 Send/read RTTY shift width
050080 00 or 01 Send/read RTTY keying polarity
050081 00 to 02 Send/read PSK tone frequency
050082 00 or 01 Send/read speech language
050083 00 or 01 Send/read speech speed
050084 00 or 01 Send/read S-level speech
050085 00 or 01 Send/read speech with a mode switch
050086 00 or 01 Send/read memo pad numbers
050087 00 or 01 Send/read main dial function
050088 00 to 02 Send/read main dial auto TS
050089 00 to 02 Send/read sub dial auto TS
050090 00 or 01 Send/read mic. up/down speed
050091 00 or 01 Send/read quick RIT/⊿TX clear func-
050092 00 to 02 Send/read SSB notch operation
050093 00 to 02 Send/read AM notch operation
050094 00 or 01 Send/read DIGI-SEL control function
050095 00 or 01 Send/read band indication for filter set
050096 00 or 01 Send/read SSB/CW synchronous tun-
050097 00 or 01 Send/read CW normal side set
050098 00 or 01 Send/read band setting for audio out-
050099 00 or 01 Send/read external keypad set for
050100 00 or 01 Send/read external keypad set for
050101 00 or 01 Send/read CI-V transceive set
050102 00 or 01 Send/read RS-232C function
050103 00 to 04 Send/read RS-232C decode speed
Description
(00=OFF, 01=ON)
(00=OFF, 01=ON)
(00=OFF, 01=ON)
(00=OFF, 01=ON)
(00=1275 Hz, 01=1615 Hz, 02=2125 Hz)
(00=170 Hz, 01=200 Hz, 02=425 Hz)
(00=Normal, 01=Reverse)
( 00=1000 Hz, 01=1500 Hz,
02=2000 Hz)
(00=English, 01=Japanese)
(00=Slow, 01=Fast)
(00=OFF, 01=ON)
operation (00=OFF, 01=ON)
(00=5 ch, 01=10 ch)
(00=MAIN, 01=MAIN+SUB)
(00=OFF, 01=Low, 02=High)
(00=OFF, 01=Low, 02=High)
(00=Low, 01=High)
tion (00=OFF, 01=ON)
( 00=Auto, 01=Manual,
02=Auto/Manual)
( 00=Auto, 01=Manual,
02=Auto/Manual)
(00=DIGI-SEL, 01=APF)
screen (00=Fix, 01=Auto)
ing function (00=OFF, 01=ON)
(00=LSB, 01=USB)
put from mic. connector
(00=MAIN+SUB, 01=SUB)
voice memory (00=OFF, 01=ON)
keyer memory (00=OFF, 01=ON)
(00=OFF, 01=ON)
(00=CI-V, 01=Decode)
( 00=300, 01=1200, 02=4800,
03=9600, 04=19200)
Cmd. Sub Cmd. Data
1A 050104 00 to 10 Send/read keyboard type
050105 0010 to
0100
050106 00 to 31 Send/read keyboard repeat rate
050107
050108 01 to 30 Send/read subnet mask
050109 00 or 01 Send/read scope indication during TX
050110 00 or 01 Send/read scope max. hold
050111 00 to 02 Send/read scope center frequency
050112 see p. 14-10 Send/read waveform color for receiv-
050113 see p. 14-10 Send/read waveform color for max.
050114 00 to 02 Send/read scope sweep speed for
050115 00 to 02 Send/read scope sweep speed for ±5
050116 00 to 02 Send/read scope sweep speed for
050117 00 to 02 Send/read scope sweep speed for
050118 00 to 02 Send/read scope sweep speed for
050119 00 to 02 Send/read scope sweep speed for
050120 00 to 02 Send/read scope sweep speed for
050121 see p. 14-10 Send/read scope edge frequencies for
050122 see p. 14-10 Send/read scope edge frequencies for
050123 see p. 14-10 Send/read scope edge frequencies for
050124 see p. 14-10 Send/read scope edge frequencies for
050125 see p. 14-10 Send/read scope edge frequencies for
050126 see p. 14-10 Send/read scope edge frequencies for
050127 see p. 14-10 Send/read scope edge frequencies for
050128 see p. 14-10 Send/read scope edge frequencies for
14-6
Description
( 00=English, 01=Japanese, 02=United
Kingdom, 03=French, 04=French
(Canadian), 05=German, 06=Portu-
guese, 07=Portuguese (Brazilian),
08=Spanish, 09=Spanish(Latin Amer-
ican), 10=Italian)
Send/read keyboard repeat delay
( 0010=100 msec., 0100=1000 msec.;
50 msec. steps)
(00=2.0 cps to 31=30.0 cps)
Send/read IP address set
( 0000000000000001=0.0.0.1 to 0255
025502550254=255.255.255.254)
(01=128.0.0.0 to 30=255.255.255.252)
(00=OFF, 01=ON)
(00=OFF, 01=ON)
set (00=Filter center, 01=Carrier point
center, 02=Carrier point center (Abs.
Freq.))
ing signal
hold
±2.5 kHz span
(00=Slow, 01=Mid., 02=Fast)
kHz span
(00=Slow, 01=Mid., 02=Fast)
±10 kHz span
(00=Slow, 01=Mid., 02=Fast)
±25 kHz span
(00=Slow, 01=Mid., 02=Fast)
±50 kHz span
(00=Slow, 01=Mid., 02=Fast)
±100 kHz span
(00=Slow, 01=Mid., 02=Fast)
±250 kHz span
(00=Slow, 01=Mid., 02=Fast)
0.03 to 1.60 MHz band
1.60 to 2.00 MHz band
2.00 to 6.00 MHz band
6.00 to 8.00 MHz band
8.00 to 11.00 MHz band
11.00 to 15.00 MHz band
15.00 to 20.00 MHz band
20.00 to 22.00 MHz band
