Icom IC-7800 Instruction Manual page 191

D Command table (continued)
Cmd. Sub Cmd. Data
1A 050025 0000 to
0255
050026 0000 to
0255
050027 0000 to
0255
050028 0000 to
0255
050029 0000 to
0255
050030 0000 to
0255
050031 00 to 07 Send/read MOD input connector dur-
050032 00 to 07 Send/read MOD input connector dur-
050033 00 to 07 Send/read MOD input connector dur-
050034 00 to 07 Send/read MOD input connector dur-
050035 00 to 02 Send/read the band selection for oper-
050036 00 to 02 Send/read the band selection for oper-
050037 00 or 01 Send/read relay type selection
050038 00 to 07 Send/read main band's external meter
050039 00 to 07 Send/read sub band's external meter
050040 0000 to
0255
050041 0000 to
0255
050042 00 to 02 Send/read reference signal in/out set-
050043 0000 to
0255
050044 0000 to
0255
050045 0000 to
0255
050046 00 to 02 Send/read screen image type
Description
Send/read AF output level to ACC-A
(0000=0% to 0255=100%)
Send/read AF output level to ACC-B
(0000=0% to 0255=100%)
Send/read S/P DIF output level
(0000=0% to 0255=100%)
Send/read MOD output level to ACC-
A (0000=0% to 0255=100%)
Send/read MOD output level to ACC-
B (0000=0% to 0255=100%)
Send/read S/P DIF MOD output level
(0000=0% to 0255=100%)
ing DATA OFF
( 00=MIC; 01=ACC-A; 02=ACC-B;
03=MIC/ACC-A; 04=MIC/ACC-B;
05=ACC-A/ACC-B; 06=MIC/ACCA/
ACC-B; 07=S/P DIF)
ing DATA1
( 00=MIC; 01=ACC-A; 02=ACC-B;
03=MIC/ACC-A; 04=MIC/ACC-B;
05=ACC-A/ACC-B; 06=MIC/ACCA/
ACC-B; 07=S/P DIF)
ing DATA2
( 00=MIC; 01=ACC-A; 02=ACC-B;
03=MIC/ACC-A; 04=MIC/ACC-B;
05=ACC-A/ACC-B; 06=MIC/ACCA/
ACC-B; 07=S/P DIF)
ing DATA3
( 00=MIC; 01=ACC-A; 02=ACC-B;
03=MIC/ACC-A; 04=MIC/ACC-B;
05=ACC-A/ACC-B; 06=MIC/ACCA/
ACC-B; 07=S/P DIF)
ating frequency band signal output to
ACC-A (00=MAIN, 01=SUB, 02=TX)
ating frequency band signal output to
ACC-A (00=MAIN, 01=SUB, 02=TX)
(00=Lead, 01=MOS-FET)
output selection
( 00=Auto, 01=S (main), 02=Po,
03=SWR, 04=ALC, 05=COMP,
06=VD, 07=ID)
output selection
( 00=Auto, 01=S (sub), 02=Po,
03=SWR, 04=ALC, 05=COMP,
06=VD, 07=ID)
Send/read main band's external meter
output level (0000=0% to 0255=100%)
Send/read sub band's external meter
output level (0000=0% to 0255=100%)
ting (00=IN, 01=OFF, 02=OUT)
Send/read reference signal frequency
setting (0000=0% to 0255=100%)
Send/read LCD unit backlight bright-
ness (0000=0% to 0255=100%)
Send/read switch indicator brightness
(0000=1 to 0255=100)
(00=A, 01=B, 02=C)
Cmd. Sub Cmd. Data
1A 050047 00 to 03
04 to 06
07 to 09
10 to 13
14 to 17
050048 00 or 01 Send/read font for other than fre-
050049 00 to 02 Send/read meter type
050050 00 or 01 Send/read meter type during wide
050051 00 or 01 Send/read peak hold set for Bar meter
050052 00 or 01 Send/read memory name indication
050053 00 or 01 Send/read audio peak filter width pop-
050054 00 or 01 Send/read manual notch width pop-up
050055 00 or 01 Send/read output signal setting for ex-
050056 00 or 01 Send/read synchronous pulse level
050057 00 or 01 Send/read opening message indica-
050058 see p. 14-10 Send/read opening message contents
050059 20000101
to
20991231
050060 0000 to
2359
050061 00 or 01 Send/read CLOCK2 function
050062 see p. 14-9 Send/read offset time for CLOCK2
050063 see p. 14-10 Send/read CLOCK2 name
050064 00 or 01 Send/read calibration marker
050065 00 or 01 Send/read confirmation beep
050066 00
01
02
03
050067 0050 to
0200
050068 0050 to
0200
050069 00 or 01 Send/read quick dualwatch function
050070 00 or 01 Send/read quick split set
050071 see p. 14-10 Send/read FM split offset –9.999 to
050072 see p. 14-10 Send/read FM split offset –9.999 to
14-5
CONTROL COMMAND
Description
Send/read frequency readout font
( 00=Italic (1), 01=Italic (2),
02=Italic (3), 03=Italic (4),
04=Round (1), 05=Round (2),
06=Round (3), 07=Shadow (1),
08=Shadow (2), 09=Shadow (3),
10=Qubic (1), 11=Qubic (2),
12=Qubic (3), 13=Qubic (4),
14=IC-780 (1), 15=IC-780 (2),
16=IC-780 (3), 17=IC-780 (4))
quency readout (00=Normal, 01=Slim)
(00=Standard, 01=Edgewise, 02=Bar)
screen or mini scope indication
(00=Edgewise, 01=Bar)
(00=OFF, 01=ON)
setting (00=OFF, 01=ON)
up indication setting
(00=OFF, 01=ON)
indication setting (00=OFF, 01=ON)
ternal display (00=OFF, 01=ON)
setting (00=L, 01=H)
tion (00=OFF, 01=ON)
Send/read date
( 20000101=1st Jan. 2000 to
20991231=31st Dec. 2099)
Send/read time
(0000=00:00 to 2359=23:59)
(00=OFF, 01=ON)
(240001=–24:00 to 240000=+24:00)
(up to 3-character)
(00=OFF, 01=ON)
(00=OFF, 01=ON)
Band edge beep OFF
Band edge beep ON (Beep sounds
with a default amateur band)
Band edge beep with user setting ON
Band edge beep with user setting/TX
limit ON
Send/read main band's beep audio fre-
quency
(0050=500 Hz to 0200=2000 Hz)
Send/read sub band's beep audio fre-
quency
(0050=500 Hz to 0200=2000 Hz)
(00=OFF, 01=ON)
(00=OFF, 01=ON)
+9.999 MHz for HF
+9.999 MHz for 50 MHz
14
