  • Page 1 UAIS TRANSPONDER FA-100...
  • Page 2 *00080932501* *00080932501* *00080932501* *00080932501* ( ( TATA TATA ) ) FA-100 FA-100 * 0 0 0 8 0 9 3 2 5 0 1 * * 0 0 0 8 0 9 3 2 5 0 1 * *IME44170D00* *IME44170D00*...

  • Page 3: Safety Instructions

    Standard Steering compass compass Only qualified personnel should work inside the FA-100 1.0 m 0.6 m equipment. CB-100 0.6 m 0.4 m Turn off the power at the switchboard before beginning the installation.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SYSTEM CONFIGURATION ................iii EQUIPMENT LISTS ..................... iv 1. MOUNTING ....................... 1 1.1 Antenna Unit ........................1 1.1.1 GPS antenna unit ....................1 1.1.2 VHF antenna ......................3 1.1.3 GPS/VHF combined antenna ................5 1.2 Transponder Unit .......................8 1.3 Junction Box ........................10 1.4 Power Supply (option) .....................11 2.

  • Page 5: System Configuration

    SYSTEM CONFIGURATION Either VHF antenna GPS/VHF GPS antenna combined antenna GSC-001 GVA-100 Distributor unit DB-1 Transponder unit FA-100 Junction box CB-100 Power supply PR-240-CE GPS Navigator * Other external equipments : Standard   : Option   Ship's mains : Local supply 24 VDC 100/110/115/200/ 12-24 VDC 220/230 VAC 1φ, 50/60Hz *: External GPS Navigation is required. Category of the units GSC-001 Exposed to the weather GVA-100...
  • Page 6 Junction Box CB-100 GPS Antenna GSC-001 Select one. GPS/VHF Combined GVA-100* Antenna Installation Materials CP24-00101* 005-950-730 For DB-1 CP24-00102* 005-950-700 For FA-100 CP05-08701* 005-949-280 For CB-100 CP24-00121* 005-952-350 For GSC-100 CP24-00141* 005-952-330 For GVA-100 Optional supply Name Type Code no.

  • Page 7: Mounting

    Antenna cable set CP20-01700 Antenna Unit : Connector Conversion Cable Assy. NJ-JP-3DXV-1 Antenna Cable FA-100 30 m Fabricate locally. (See next page.) Waterproofing connector Wrap connector with vulcanizing tape and then vinyl tape. Bind the tape end with a cable-tie. Waterproofing connector b) Antenna cable set CP20-01710 (8D-FB-CV, 50m) Connect the cable the same as a) above.
  • Page 8 How to attach the connector N-P-8DFB for cable 8D-FB-CV Dimensions in millimeters. Outer Sheath Armor Inner Sheath Shield Remove outer sheath and armor by the dimensions shown left. Expose inner sheath and shield by the dimensions shown left. Cover with heat-shrink tubing and heat. Cut off insulator and core by 10mm.

  • Page 9: Vhf Antenna

    • Install the VHF whip antenna referring to the outline drawing at the back of this manual. Separate this antenna from other VHF radiotelephone antennas as shown on the next page to prevent interference to the FA-100.
  • Page 10 Horizontal separation distance Other VHF whip antenna Whip antenna for AIS (GPS/VHF combined antenna) More than 10 m Vertical separation distance More than 2.8 m More than 0.5 m • When coaxial cable RG-10U/Y (shipyard supply) is used, attach the coaxial plug M-P-7 (dockyard supply) as shown on the next page.

  • Page 11: Gps/Vhf Combined Antenna

    How to attach the plug M-P-7 Lay the coaxial cable and attach an M-type plug (if necessary) to the cable as follows. 30 mm 1. Remove the sheath by 30 mm. Sheath 5 mm 2. Bare 23 mm of the center conductor. Trim 2 mm braided shield by 5 mm and tin.
  • Page 12 Mounting procedures 1. Dismount the bottom cover, cut the cable-tie inside the unit and take out the coaxial connector attached to the combined box. 2. Loosen four screws to loosen whip antenna fixture and pull out the coaxial connector coming from the combined box through the hole in the whip antenna fixture.
  • Page 13 The top of the stanchion come into contact with the flange. Stanchion Installing distributor unit DB-1 The length of the cable between the distributor unit and transponder unit is 1 m so locate the distributor unit within 1 m from the transponder unit. Fix the distributor unit on the bulkhead, facing the cable entrance downward. Remove the lid of the distributor unit and secure the unit with two tapping screws.

  • Page 14: Transponder Unit

    1.2 Transponder Unit The transponder unit can be installed on a desktop or flush mounted in a panel. Install it on the chart table or near the steering place, referring to the outline drawing. When selecting a mounting location for the transponder, keep the following in mind: •...
  • Page 15 Flush mounting Optional flush mount kit A or B is required for flush mounting. For mounting dimensions, refer to the outline drawing at the back of this manual. Flush mount kit A: Type OP24-1 Code no. 005-950-740 Name Type Code no. Cosmetic panel 24-003-2811 100-299-540...

  • Page 16: Junction Box

    1.3 Junction Box Mount the junction box where the junction box is protected from rain and water splash. Mounting 1. Open the lid of the junction box and fix the junction box with four tapping screws (5x20). Avoid bundling the 3.3 m cable of the junction box together with any power cable.

  • Page 17: Power Supply (Option)

    1.4 Power Supply (option) The length of the power cable between the power supply and the transponder unit is 3.5 m. Keep this length in mind when selecting a mounting location. A longer cable should not be used – voltage drop will result, affecting performance. When selecting a mounting location for the unit, keep the following in mind: •...

  • Page 18: Wiring

    AUX-2 TTYCS-1Q** AD-10 IN Gyrocompass AD-100 EXTRA I/O AIS sentence out Transponder (4800 bps) unit Power Supply FA-100 PR-240-CE Alarm out GPS receiver Heading sensor 1.5 sq Speed sensor or ROT Approx. 3.3 m DPYC-1.5** Beacon receiver AIS data In/Out...
  • Page 19 **: DPYC-1.5, TTYCS-1Q and TTYCS-4 are Japan Industry Standard cable. Use them or the equivalents. DPYC-1.5 TTYCS-1Q (Four core twisted) Armor Armor Sheath Sheath φ = Shield 11.7 mm φ = 11.3 mm Conductor Conductor S = 1.5 mm S = 0.75 mm φ...
  • Page 20 Cable Connection at Junction Box Cable fabrication Armor Sheath Shield 5 to 6 mm Clamp here by cable clamp. Connection Core 5-6 mm Procedure 1. Insert driver from direction 1 . 2. Tilt slightly toward 2 . 3. Insert cable core to 3 .

  • Page 21: Input/Output Signal

    61162-1/2. The protocol is RS422. If there is no HDT signal from a gyrocompass, connect the gyrocompass signal (Synchro or step signal) to the “AD-10 IN” port (D-sub 9 pins) of the transponder unit via the FURUNO A/D Converter AD-100 (See page 16).

  • Page 22: Input/Output Of Ais Signal

    3.2 Input/Output of AIS Signal Three input/output ports are provided for RS-422 protocol, based on the IEC 61162-1/2. Data transmission rate is selectable from 4800 bps and 38.4 kbps. Normally, Radar/ECDIS/PC, etc. are connected to these ports to exchange data with the AIS.

  • Page 23: Input Of Gyrocompass Signal

    If the gyrocompass has no HDT signal, the AD-10 format (FURUNO format) signal can be input via the FURUNO A/D Converter AD-100. Connect the AD-100 to the “AD-10 IN” port (D-sub 9 pin) on the rear panel of the transponder unit.

  • Page 24: Lan Input/Output

    PC), use a LAN cable category 4 or higher with shield (SDT). Connect it to the PC with an RJ-45 connector, and connect to the FA-100 with a D-sub 9 pin connector, to avoid noise leakage. To use a commercial LAN cable, remove one connector and solder a D-sub 9 pin connector, supplied in the installation materials.

  • Page 25: Jumper Setting In The Junction Box

    If multiple equipment are connected to an output port of an external equipment, change to jumper block setting to between the #1 and #2 pins to reduce the load on the FA-100. Then, the input impedance of the RS-422 RX lines in the FA-100 becomes more than 2.4 k ohms.

  • Page 26: Input/Output Sentences

    3.7 Input/Output Sentences 1) SENSOR 1, SENSOR2, and SENSOR3 ports These ports can receive IEC61162-1/2 standard data. The transmission rate of sensor 1, 2, and 3 is selectable from 4800 bps and 38.4 kbps through the menu. Input sentences are as follows: $xxDTM, $xxGBS, $xxGGA, $xxGLL, $xxGNS, $xxHDT $xxOSD, $xxRMC, $xxROT, $xxVBW, $xxVTG Note: The talker of the underlined sentences has priority as...

  • Page 27: Changing Ship's Mains Specifications

    3.8 Changing Ship’s Mains Specifications The power supply PR-240 is shipped ready for connection to a 200-230 VAC ship’s mains. If the ship’s mains is 100 VAC – 115 VAC, change the tap connection and terminal board connection as below. Attach label supplied as accessories to the punch mark in the front panel according to the ship’s mains.

  • Page 28: Setting And Adjustment

    NOW STARTING CHECKING MEMORY 3. After the following window appears, enter the password. Note that the password is known by only the FURUNO dealer. [ENTER PASSWORD] PASSWORD: 4. Press the [ENT] key to display the SET MMSI & IMO# window.

  • Page 29: Setting Ship Name And Call Sign

    4.2 Setting Ship Name and Call Sign 1. Press the [MENU] key to open the main menu. [MENU] 1 TARGET DATA 2 PLOTTER 3 OWN DATA 4 SET MSG 5 INIT SETTINGS 6 SYSTEM SETTINGS 7 DIAGNOSTICS Main menu 3. Press the [5] key to open the INIT SETTINGS sub-menu. [INIT SETTINGS] 1 SET SHIP DATA 2 SET DESTINATION...

  • Page 30: Setting Gps Antenna Position And Ship's Type

    6. Press the [NEXT] key to select C.SIGN. 7. Enter call sign, using up to seven alphanumeric characters. 8. Press the [ENT] key to register data. The INIT SETTINGS sub-menu appears. 4.3 Setting GPS Antenna Position and Ship’s Type 1. In the INIT SETTING sub-menu, press the [6] key to open the SET ANTENNA POS window.
  • Page 31 7. Press the [NEXT] key to select TYPE NO. Confirm type of ship with ship’s captain before setting it. 8. Press the [2], [4], [6] or [8] key as appropriate to select your ship’s type, referring to the list on below. Table: Type name 10 FUTURE USE ALL SHIPS OF THIS TYPE...

  • Page 32: System Settings

    10. Press the [MENU] key. The SAVE confirmation window appears. SAVE ? CANCEL SAVE confirmation window 11. With YES selected, press the [ENT] key to save the data. 4.4 System Settings 1. Press the [MENU] key to open the main menu. 2.
  • Page 33 5. Select the appropriate data transmission rate from 4800 bps and 38.4 kbps for PC I/O, SNSR 1, SNSR 2, SNSR 3, LR, BCON (beacon receiver), EXTRA1 and EXTRA2, by pressing the [SFT] key. To select each item, press the [NEXT] key. To go backward, press the [NEXT] key while pressing the [SFT] key.
  • Page 34 17. Press the [NEXT] key to select EX1, LR, PC or LAN. 18. Press the [SFT] key to select ENBL (enable) or DSBL (disable) as appropriate. This setting is for communication between FA-100 and each external equipment. “DSBL” disables communication with selected item.
  • Page 35 PORT NO. 10000 SET LAN (IP ADDR) window 21. If the FA-100 is connected to a network, enter IP address, sub net mask and port number with the numeric keys and the [NEXT] key. 22. Press the [ENT] key and then the [MENU] key to return to the SYSTEM SETTINGS sub-menu.
  • Page 36 This page is intentionally left blank.
  • Page 37 N A M E DESCRIPTION/CODE № O U T L I N E Q'TY ユニット ユニット ユニット ユニット UNIT UNIT UNIT UNIT ﾄﾗﾝｽﾎﾟﾝﾀﾞ部 FA-100 TRANSPONDER UNIT 000-053-889 工事材料 工事材料 INSTALLATION MATERIALS INSTALLATION MATERIALS CP24-00102 CP24-00102 工事材料 工事材料 INSTALLATION MATERIALS INSTALLATION MATERIALS...
  • Page 38 A - 2 ＰＡＣＫＩＮＧ　ＬＩＳＴ ＰＡＣＫＩＮＧ　ＬＩＳＴ ＰＡＣＫＩＮＧ　ＬＩＳＴ ＰＡＣＫＩＮＧ　ＬＩＳＴ 24AA-X-9853 -1 GVA-100 GVA-100 GVA-100 GVA-100 N A M E DESCRIPTION/CODE № O U T L I N E Q'TY ユニット ユニット ユニット ユニット UNIT UNIT UNIT UNIT 分配器 DB-1 DISTRIBUTER UNIT 000-053-854 複合空中線部...
  • Page 39 A - 3 ＰＡＣＫＩＮＧ　ＬＩＳＴ ＰＡＣＫＩＮＧ　ＬＩＳＴ ＰＡＣＫＩＮＧ　ＬＩＳＴ ＰＡＣＫＩＮＧ　ＬＩＳＴ 24AA-X-9851 -3 CB-100 CB-100 CB-100 CB-100 N A M E DESCRIPTION/CODE № O U T L I N E Q'TY ユニット ユニット ユニット ユニット UNIT UNIT UNIT UNIT 接続箱 CB-100 JUNCTION BOX 000-053-907 工事材料...
  • Page 40 A - 4...
  • Page 41 A - 5...
  • Page 42 A - 6...
  • Page 43 A - 7...
  • Page 44 A - 8...
  • Page 46 D - 2...
  • Page 47 D - 3...
  • Page 49 D - 5 Jan. 15, '03...
  • Page 50 D - 6...
  • Page 51 D - 7...
  • Page 56 S - 1 Dec. 18,'02...
  • Page 59 Appendix 6) Connection to FEA-2105 AP6.1 Connection AP6.1 Connection To connect FA-100 to FEA-2105; 1. Install high speed SIF card to the corresponding port in FEA-2105 A-adapter. The card is identified by the label “IEC 61162” from other cards. TS2 TS1...
  • Page 60 AP6.1 Connection 2. Connect CB-100 of FA-100 to A adapter of FA-100 as shown in Fig.AP6.1.3. The AIS port, “L/R ECDIS/RADAR”, “EXTRA I/O” or “PC I/O” is used on FA-100. FEA-2105 CB-100 CB-100 (48P type) (41P type) Port Signal FA-100 A adapter Terminal No.
  • Page 61 AP6.2 Updating FEA-2105 system program AP6.2 Updating FEA-2105 system program The FEA-2105 system program which supports AIS function is version 3.01 and above. Program version of FEA-2105 is displayed at the lower right corner. System version If the program is lower than version 3.01, follow the procedure below. Closing ECDIS program 1.
  • Page 62 AP6.2 Updating FEA-2105 system program 3. Press [TAB] while pressing [ALT] until “ECA WATCH” appears in the list box. “ECA WATC” window appears. ECA WATCH ANTS.ECDIS PROCESS STARTER This window control execution of various ECDIS software computers. To move this window in background click chart area with SELECT push button.
  • Page 63 AP6.2 Updating FEA-2105 system program 6. Press [F4] while pressing [ALT]. The display changes to “Windows NT”. Updating ECDIS program (Ver3.01 and above) 7. Insert the program CD-ROM (ver.3.01 and above) to CDROM drive in EC-1000 (EC-1000B). 8. Run “Windows NT explorer” in “PROGRAM” holder in “START” menu. 9.
  • Page 64 AP6.2 Updating FEA-2105 system program 11. Move the pointer onto “Setup. exe” file icon and then press [SELECT] twice to open the file. The following window appears. Warning Installation can’t shutdown ECDIS sofware automatically Shutdown ECDIS software befor continuing 1. Use shutdown the ECDIS from EACWATCH 2.
  • Page 65 AP6.2 Updating FEA-2105 system program 14. Move the pointer onto [NEXT] and press [SELECT]. The “User info” window appears. 15. Move the pointer onto [NEXT] and press [SELECT]. Re-enter the Password and HASP.pin number as below. Password: ECDIS HASP.pin: 2371 16.
  • Page 66 AP6.2 Updating FEA-2105 system program 18. When the window below appears, move the pointer onto [OK] and press [SELECT]. The “Setup complete window appears. 19. Select [Yes] and move the pointer onto [Finish] and press [SELECT]. The ECDIS starts automatically. Yes, I want to restart my computer now No, I will restart my computer later AP6-8...
  • Page 67 AP6.3 Setting AP6.3 Setting AP6.3.1 Setting on FA-100 Press [MENU][6][1][1] and set “I/O SPEED” to 38.4 k. Port I/O SPEED Port I/O SPEED PC I/O 38.4 k 38.4 k SNSR 1 4800 BCON 4800 SNSR 2 4800 EXTRA 1 38.4 k...
  • Page 68 AP6.3 Setting 3. Move the cursor onto “Installation Parameter” and press [SELECT] to open “Installation Parameter”. Installation parameters Sensor Parameters Set parameter default Sensor Channel usage Workstation parameters Set Signal Workstation Mode Workstations Cancel 4. Move the pointer onto in “Sensor Parameter” list box and press [SELECT] to show “SENSOR”...
  • Page 69 AP6.3 Setting 6. Set items in AIS parameter setting menu as shown in the table below. (Select screened parameters.) Item Setting Remarks Connected A-Adapter 1 to 16 Set the port number to which AIS is connected. IEC61162-2 Device (38400 bit/s) interface IEC61162-1 (4800 bit/s) Normal IEC61993-2...
  • Page 70 AP6.3 Setting AP6.3.3 Displaying AIS target 1. Press [CHART DISPLAY] on FEA-2105. The following “Chart display” window appears. If not, move the pointer onto the “Tracking” and press [SELECT]. Chart display Chart Standerd Other Tracking Mariner Route Past tracks Other Ship System Ship Primary Ship Secndery...
  • Page 71 AP6.3 Setting Max. count To set the maximum number of the nearest AIS target from the own ship, move the pointer onto in “Max. count” box and press [SELECT]. Select 20, 40, 100 or 200 and press [SELECT]. Max. range Move the pointer onto in “Max.
  • Page 72 AP6.4 Checking AIS signal to FEA-2105 AP6.4 Checking AIS signal to FEA-2105 When RX LED in FEA-2105 A-adapter blinks, FEA-2105 receives the signal normally. LED number corresponds to the T.B. number. TIF-1 TIF-4 AP6-14...
