Mount the Siren to the mounting bracket by turning the Siren clockwise.

Secure the captive locking screw (see Figure 3-1)

5. Testing the Siren

Once the Siren has been registered test the unit according to the following testing

procedure:

To perform a Siren test

Go to the main menu and select [7]>[0]>[3]>[1] (Service> Tests> WL Siren Test).

Select a siren from the list (1-4) and press '√ʹ. The selected Siren is sounded

briefly.

To delete a Siren from the system:

Set the system to Delete mode.

Go to the main menu and select [9]>[1]>[5]>[1] (Programming > Devices >

Siren>WL Siren)

Select a siren from the list (1-4) and press '√ʹ.

Press >3, and press'√ʹ. Upon the 'OK' conﬁrmation request, press ʹ√ʹ

Open the Siren and take out the battery.

Press the tamper switch. While the tamper switch is being pressed insert the

battery. Within five seconds open the tamper and close it again.

Mounting

Bracket

Figure 4-1: Attaching the mounting bracket

Tamper

Protection

Screw
