1. Introduction

The EL-4723 is a 2-Way Wireless Indoor Siren for use with the iConnect 2-Way security
system. In the event of an alarm the control system activates the siren. The Wireless
Indoor Siren is sounded until the end of the control-system-programmed siren cutoff.

2. Location of the Siren

Consider the following before mounting the Siren:
• Choose a suitable mounting location for the Siren.
• The Siren should be mounted on a flat surface in a highly visible position for
maximum deterrence against potential intruders.
• Before permanently mounting the Siren, test the reception from the exact
mounting position.
Note:
Always wear ear protectors when installing indoor/outdoor Sirens

3. Registering the Siren

The EL-4723 must identify itself to the iConnect 2-Way receiver as follows:
1. Set the system to registration mode.
• Go to the main menu and select [9]>[1]>[5]>[1] (Programming > Devices >
Siren>WL Siren)
• Select a siren from the list (1-4) and press '√ʹ.
2. Release the mounting bracket captive locking screw (see Figure 3-1).
Figure 3-1: Releasing the locking screw Figure 3-2: Inserting the batteries
3
