- Page 1 FOUR CHANNEL H264 DIGITAL VIDEO RECORDER ART. 49807 Please read this manual thoroughly before use and keep it for future reference. Via Don Arrigoni, 5 24020 Rovetta S. Lorenzo (Bergamo) http://www.comelit.eu – e-mail: export.department@comelit.it...
-
Page 3: Compliance Notice Of Fcc
H264 Digital Video Recorder art. 49807 WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"... -
Page 4: Important Safeguards
User’s Manual Important Safeguards 1. Read Instructions 14. Damage requiring Service All the safety and operating instructions should be read before the Unplug this equipment from the wall outlet and refer servicing to appliance is operated. qualified service personnel under the following conditions: A. -
Page 5: Table Of Contents
H264 Digital Video Recorder art. 49807 Table of Contents Chapter 1 — Introduction ..................1 Features ........................1 Package Contents ....................1 Rear Panel Connectors ..................1 Factory Reset ......................3 Front Panel Controls .....................3 Chapter 2 — Operation .....................4 Turning on the Power ....................4 Live Monitoring ......................5... - Page 6 User’s Manual...
-
Page 7: Chapter 1 - Introduction
H264 Digital Video Recorder art. 49807 Chapter 1 — Introduction FEATURES Your color digital video recorder (DVR) provides recording capabilities for 4 camera inputs. It provides exceptional picture quality in both live and playback modes, and offers the following features: 4 Composite Input Connectors Compatible with Color (NTSC or PAL) and B&W (CCIR and EIA-170) Video Sources... - Page 8 User’s Manual ① Video In: Connect the coaxial cables from the video sources. ② Video Out: Connect a main monitor. ③ VGA: Connect a VGA monitor. The VGA monitor is automatically detected when you connect it. ④ Alarm In: Connect alarm-in devices. You can use external devices to signal the DVR to react to events. Mechanical or electrical switches can be wired to the AI (Alarm-In) and G (Ground) connectors.
-
Page 9: Factory Reset
H264 Digital Video Recorder art. 49807 FACTORY RESET To reset the unit, you will need a straightened paperclip: Turn the DVR off. Poke the straightened paperclip in the unlabeled hole to the right of the Alarm Output connector, and turn the DVR on. -
Page 10: Chapter 2 - Operation
User’s Manual Chapter 2 — Operation TURNING ON THE POWER Connecting the power cord to the DVR turns on the unit. The unit will take approximately 30 seconds to initialize. The DVR provides five operation modes: live monitoring, recording, playback, searching and PTZ mode. When the DVR operates first, it displays quad screen and starts recording. -
Page 11: Live Monitoring
H264 Digital Video Recorder art. 49807 LIVE MONITORING To Change Screen Mode Full-screen Pressing a camera button in quad screen mode displays that camera in full screen. Quad screen Pressing the DISPLAY button in full screen mode displays four cameras at once. -
Page 12: Playback
User’s Manual To Enter Recording Mode Time-Lapse Recording Main Menu RECORD Select in Record Mode. − Set up the recording speed and quality for time-lapse recording. − Set up the recording schedule. − Event Recording Main Menu RECORD − Select in Record Mode. - Page 13 H264 Digital Video Recorder art. 49807 To Enter Searching Mode Pressing the MENU button in the playback mode enters the Search mode and displays the Search Menu. Selecting Exit Search exits the search mode. Select the desired search mode in the search menu.
- Page 14 User’s Manual Record Channels: Select channels o include every recorded event regardless of the event type in – your search condition. Disk Almost Full, Disk Bad, Disk Temperature or Disk S.M.A.R.T.: Select to include self-diagnostic – events in your search condition. Clip Copy It allows you to copy recorded video clips to external storages.
-
Page 15: Ptz Control
H264 Digital Video Recorder art. 49807 PTZ CONTROL PTZ control is available for only PTZ cameras that allow pan, tilt, zoom, focus or preset etc. To Enter PTZ Mode ① Connect a PTZ device to the DVR and set up the PTZ device. Refer to Chapter 3 –... - Page 16 User’s Manual To Run Preset ① Pressing the MENU button in PTZ mode displays the PTZ menu. ② Move to Set Preset in the PTZ menu and select it by pressing the button displays the Set (Play/Pause) button. Pressing the Preset screen.
-
Page 17: Chapter 3 - Configuration
H264 Digital Video Recorder art. 49807 Chapter 3 — Configuration OVERVIEW How to Enter Main Setup Menu ① Pressing the MENU button in the live monitoring mode enters a Main Setup menu. Entering a Main Setup menu is password protected. -
Page 18: Main Menu
User’s Manual How to Enter Characters ① Select the desired item and press the button, and a virtual keyboard is displayed. ② Move to the desired character by pressing the arrow buttons, and enter the desired character by pressing the button and using space, (upper or lower case change),... - Page 19 H264 Digital Video Recorder art. 49807 SYSTEM Language: Choose the desired language. Version: Displays the software version of the DVR. To upgrade the software, connect the USB device containing the upgrade package file (.rui) to the USB port on the front panel and select Upgrade…...
- Page 20 User’s Manual OSD: Choose to enable or disable OSD (On Screen Display). None: Choose to not display OSD information. – Camera: Choose to display camera title, recording status and PTZ icons on each camera screen. – Status: Choose to display zoom, network connection, freeze, sequence and recycle icons, and date/ –...
- Page 21 H264 Digital Video Recorder art. 49807 NOTE: When set to the H.264 codec, the DVR can record more images by compressing more effectively than using the MPEG-4 codec. However, the recording speed might decrease depending on the display option and DVR’s operation mode.
- Page 22 User’s Manual No.: Select to set the alarm-in detection for entire alarm-in devices (No.) or an individual device. Title: Choose to change the name of all or each alarm-in device. Type: Set up each input as NO (Normally open) or NC (Normally closed).
- Page 23 H264 Digital Video Recorder art. 49807 Type: Choose the type of network configuration from: Manual, DHCP and ADSL (with PPPoE). Manual: Select when using a static IP address for network – connection and set up LAN parameters manually. Adjust the numbers of the IP Address, Gateway and Subnet Mask.
- Page 24 User’s Manual NOTES: You will need to get the IP address or domain name of the DVRNS server from your network administrator. When using the NAT (Network Address Translation) device, refer to the NAT manufacturer’s instructions for the proper network settings using NAT. The DVR name you entered should be checked by selecting the Check button, otherwise the DVRNS changes will not be saved.
- Page 25 H264 Digital Video Recorder art. 49807 S.M.A.R.T.: Displays S.M.A.R.T. information of the storage. Good: The storage condition is normal. – Bad: Data cannot be written on or read from the storage device. – N/A: The S.M.A.R.T. monitoring is not working or supported.
-
Page 26: Appendix
User’s Manual Appendix WEBGUARD WebGuard allows you to access a remote DVR, monitor live video images and search recorded video using Internet Explorer web browser anytime from virtually anywhere. Computer system requirements for using WebGuard are: ® ® ® Operating System: Microsoft Windows 2000, Microsoft Windows XP or Microsoft Windows Vista... - Page 27 H264 Digital Video Recorder art. 49807 NOTES: When running WebGuard in the Microsoft Windows Vista operating system, it is recommended that you start Internet Explorer with elevated administrator permissions. Click the right mouse button on the Internet Explorer icon and select the Run as administrator option from the context menu. Otherwise, some functions of the WebGuard might be limited.
- Page 28 User’s Manual ⑩ Save Image: Click to save the current image as a bitmap or JPEG file format. ⑪ Setup: Click to set up the image drawing mode and OSD display. You can adjust the display speed by changing the image drawing mode, and select OSD information to be displayed on the screen. ⑫...
-
Page 29: Dvr Name Service (Dvrns)
H264 Digital Video Recorder art. 49807 ⑥ Playback Function Buttons: The Playback Function Buttons include fast backward, pause, play, fast forward, go to the first image, go to the previous image, go to the next image, and go to the last image. -
Page 30: Clip Player
User’s Manual System Configuration STEP 1 (DVR DVRNS Server): Register the unit name and IP address of the DVR during the NETWORK – DVRNS setup. This unit name and IP address will be registered on the DVRNS server directly. STEP 2 (WebGuard DVRNS Server): Request the IP address of the DVR using the registered unit name of the DVR you want to connect to. - Page 31 H264 Digital Video Recorder art. 49807 Screen Size: Changes the Clip Player screen size. – OSD Setup…: Selects options to display on the screen. – Enable Audio: Plays audio while playing back recorded video that has recorded audio. (Single-Screen –...
-
Page 32: Time Overlap
User’s Manual TIME OVERLAP If the DVR’s time and date have been reset to a time that is earlier than the existing recorded video, it is possible for the DVR to have more than one video stream in the same time range. In this case, you can search overlapping video streams individually by selecting a specific segment. -
Page 33: Error Code Notices
H264 Digital Video Recorder art. 49807 ERROR CODE NOTICES SYSTEM UPGRADE RELATED CLIP COPY RELATED Description Description Unknown error. Unknown error. File version error. Device error. Operating system version error. Mounting failed. Software version error. No media. Kernel version error. -
Page 34: Connector Pin Outs
User’s Manual CONNECTOR PIN OUTS I/O Connector Output AI (1 to 4) Alarm Inputs 1 to 4 GND (Chassis Ground) Alarm Reset In Alarm Out (Normally Closed) Common Alarm Out (Normally Open) Input RS485 Connector Master Unit Slave Unit − TX−... -
Page 35: Specifications
H264 Digital Video Recorder art. 49807 SPECIFICATIONS VIDEO Signal Format NTSC or PAL (Auto detect) Video Input Composite: 4 inputs, 1 Vp-p, auto-terminating, 75 Ohms Composite: One (BNC), 1 Vp-p, 75 Ohms Monitor Outputs VGA: One (Auto detect) Composite: 720x480 (NTSC), 720x576(PAL) - Page 36 User’s Manual Via Don Arrigoni, 5 24020 Rovetta S. Lorenzo (Bergamo) http://www.comelit.eu – e-mail: export.department@comelit.it V1.5...
