Summary of Contents for Comelit IPHYB008A
-
Page 3: Dvr Rear Panel
Digital Video Recorder art. IPHYB008A-IPHYB016A DVR Rear Panel 16-Channel DVR Rear Panel Video Input Video Loop Through Factory Reset Switch HD/SD Out Selector Network Port iSCSI Port eSATA Port RS232C Port RS485 Port Alarm Input/Output Audio In/Out Video Out Power Cord Connector ... -
Page 4: Playback Buttons
Quick Reference Manual Camera Buttons: Pressing the individual camera buttons will cause the selected camera to display full screen. Buttons 1 to 9 are also used to enter passwords. Jog Dial: When in the playback mode, you can play video forward image-by-image by turning the Jog Dial clockwise and backward image-by-image by turning the Jog Dial counterclockwise. -
Page 5: Turning On The Power
Digital Video Recorder art. IPHYB008A-IPHYB016A USB Port: The USB port is provided to connect external hard disk or flash drives for video clip copying or system upgrades. A USB mouse or PostScript™ USB printer can be connected to the USB port. - Page 6 Quick Reference Manual Map of Setup Screens NOTE: Refer to User’s Manual (on CD) for the setup instructions for details.
-
Page 7: Live Monitoring
Digital Video Recorder art. IPHYB008A-IPHYB016A Live Monitoring As soon as the DVR completes its initialization process, it will begin showing live video on the attached monitor and playing live audio through the attached speaker. The default mode is to display all cameras at once. -
Page 8: Searching Video
Quick Reference Manual Searching Video While in the search mode, pressing the button displays the following Search menu on the right edge MENU of the screen. Pressing the button again hides the menu. You can navigate through menus and items MENU by pressing the arrow buttons. -
Page 9: Remote Program
Digital Video Recorder art. IPHYB008A-IPHYB016A Remote Program RASplus RASplus (Remote Administration System Plus) program, which is designed to be used with remote digital video recorders (DVRs, network video transmitters and network cameras included), is an integrated software program that controls system management, video monitoring, video recording and image playback of multiple remote sites. -
Page 10: Playback And Search
Quick Reference Manual Playback and Search To connect a remote site on the Search screen, select the site or camera you want to connect to in the Remote Site or Favorite Sites panel and then drag and drop it in the desired position on the screen. The icon will be displayed on each Search screen. -
Page 11: Web Monitoring
Digital Video Recorder art. IPHYB008A-IPHYB016A Web Monitoring WebWatch is a remote web monitoring program that allows you to monitor live video transmitted in real-time from the remote DVR. ① Click the to log out the WebGuard program. ② Click the to access to the web search mode. -
Page 12: Web Search
Quick Reference Manual Web Search WebSearch is a remote web search program that allows you to search recorded video on the remote DVR. ① Click the to log out the WebGuard program. ② Click the to access to the web monitoring mode. ③... - Page 13 Digital Video Recorder art. IPHYB008A-IPHYB016A Selecting a camera on the screen and clicking the right mouse button displays the text menu screen. You can change the camera title, play audio, change the image aspect ratio, turn on the interlacing filter and eliminate aliasing effects.
