B.4.4 Serial Communication
The Prototyping Board allows you to access five of the serial ports from the RCM4100
series of modules. Table B-5 summarizes the configuration options. Note that Serial Ports
E and F can be used only with the Prototyping Board.
Table B-5. Prototyping Board Serial Port Configurations
Serial Port
A
B
C
D
E
F
Serial Ports E and F may be used as serial ports, or the corresponding pins at header loca-
tion J2 may be used as parallel ports.
User's Manual
Header
Default Use
J2
Programming Port
A/D Converter
J2
(RCM4100 only)
J2, J4
J2, J4
J2
J2
Alternate Use
RS-232
RS-232
—
—
RS-232
—
—
—
—
—
93
