Rabbit RabbitCore RCM4100 User Manual page 35

Table 2. RCM4100 Series Pinout Configurations (continued)
Pin Pin Name
40 PD0
41 PD1
42 PD2
43 PD3
44 PD4
45 PD5
46 PD6
47 PD7
User's Manual
Default Use
I/O Strobe I0
Timer C0
Input/Output INT0
SCLKD/TCLKF
QRD1B
IA6
I/O Strobe I1
Timer C1
Input/Output INT1
RXD/RCLKF
QRD1A
Input Capture
I/O Strobe I2
Timer C2
Input/Output DREQ0
TXF/SCLKC
QRD2B
IA7
I/O Strobe I3
Timer C3
Input/Output DREQ1
RXC/RXF
QRD2A
Input Capture
I/O Strobe I4
Input/Output PWM0
TXB/TCLKE
IA6
I/O Strobe I5
Input/Output PWM1
RXB/RCLKE
Input Capture
I/O Strobe I6
Input/Output PWM2
TXA/TXE
IA7
I/O Strobe I7
Input/Output PWM3
RXA/RXE
Input Capture
Alternate Use
RCM4110/RCM4120 only
Notes
31
