gaincode
RETURN VALUE
0 if successful
-1 if address is invalid or out of range.
SEE ALSO
anaInEEWr, anaInCalib
User's Manual
anaInEEWr (continued)
the gain code of 0 to 7. The gaincode parameter is ignored when
channel is ALLCHAN.
Gain
Gain Code
Multiplier
0 ×1
1 ×2
2 ×4
3 ×5
4 ×8
5 ×10
6 ×16
7 ×20
* Applies to Prototyping Board.
*
Voltage Range
(V)
0–22.5
0–11.25
0–5.6
0–4.5
0–2.8
0–2.25
0–1.41
0–1.126
