4.3.2 Standalone Operation of the RCM4100

Once an RCM4100 series module has been programmed successfully, remove the pro-

gramming cable from the programming connector and reset the RCM4100 series module.

The module may be reset by cycling the power off/on or by pressing the

the Prototyping Board. The module may now be removed from the Prototyping Board for

end-use installation.

CAUTION: Power to the Prototyping Board or other boards should be disconnected

when removing or installing your RCM4100 series module to protect against inadvert-

ent shorts across the pins or damage to the RCM4100 if the pins are not plugged in cor-

rectly. Do not reapply power until you have verified that the RCM4100 series module is

plugged in correctly.
