Header
Description
JP8
Data SRAM Size
JP9
LN1 or PD1 on J2 pin 41
JP10
PE5 or SMODE0 Output on J2
JP11
PE6 or SMODE1 Output on J2
JP12
PE7 or STATUS Output on J2
NOTE: The jumper connections are made using 0 Ω surface-mounted resistors.
User's Manual
Table A-8. RCM4100 Jumper Configurations
Pins Connected
1–2 512K
2–3 256K
1–2 LN1
2–3 PD1
1–2 PE5
2–3 SMODE0
1–2 PE6
2–3 SMODE1
1–2 PE7
2–3 STATUS
Factory
Default
×
RCM4100
RCM4110
×
×
×
79
