Table B-6. Prototyping Board Jumper Configurations (continued)
Header Description
JP23 LN4_IN–LN6_IN
JP24 LN0_IN–LN3_IN
JP25 Thermistor Location
NOTE: Jumper connections JP3–JP10, JP12, JP14, JP16, JP18, JP23, and JP24 are made
using 0 Ω surface-mounted resistors. Jumper connections JP11, JP13, JP15, JP17, and
JP19–JP22 are made using 10 kΩ surface-mounted resistors.
NOTE: The LN0–LN7 signals are useable only when a RabbitCore module with an A/D
converter is used with the Prototyping Board. The RCM4110 and RCM4120 do not
have an A/D converter.
User's Manual
Pins Connected
1–2 Tied to analog ground
2–3 Tied to VREF
1–2 Tied to analog ground
2–3 Tied to VREF
1–2
Factory
Default
×
×
n.c.
