Video - Digital Watchdog MEGApix DWC-MV421D User Manual

WEBVIEWER*
D i s p l a y S c r e e n > S e t u p > V i d e o & A u d i o > P r i v a c y Z o n e
The MV421 MEGAPIX camera offers up to 30 privacy zone settings. To set Privacy Zones:
1. Change Mode to On. Click Apply. By default, all 30 privacy zones will be displayed.
2. Select the color of the zone and transparency of the color from the drop down list. Click Apply.
3. Select the zones you want to view and/or modify. Use the Show All button to display all 30 privacy zones, or Hide
All to deselect them and select only a single privacy zone. After selecting the privacy zone you want to modify,
click Apply.
Set the zone's size and location, using the grid lines. In Local Settings, select the zone you
4.
want to modify, then select the position: Horizontal Position: 0~57; Vertical Position: 0~31;
0~34.
Click Apply after each modification
to verify the size and position
match your requirements.
1
3
4
Width: 0~60; Height:
2
35
