WEBVIEWER*
D i s p l a y S c r e e n > S e t u p > V i d e o & A u d i o > S t r e a m
S e t t i n g s
The Recommended Stream Settings are indicated on the image to the left. This is also the factory default settings.
1. Name: Set a distinguished name to each stream to identify each.
2. Resolution: Set Resolution for each stream. The better the resolution of the video, the more bandwidth it will
require to stream images.
3. Compression Type (Codec): Select the type of compression to use when outputting the video.
4. Data Transfer Speed: Set encoding bitrate if H.264 and MPEG4 compression type is selected.
5. Framerate: Select from 0fps to 30fps.
6. MJPEG Quality: Set MJPEG image quality. This is only available when the compression is set to MJPEG. The
higher the quality, the more bandwidth will be required to stream the image.
7. Select Apply to save changes.
1
3
5
7
2
4
6
