WEBVIEWER*
D i s p l a y S c r e e n > S e t u p > V i d e o & A u d i o > C o l o r S e t t i n g s
Initially, the factory default settings will appear; however, you may customize the Color Settings for your MEGAPIX
camera.
White Balance: Mode - Also known as Color Balance. This gives the camera a reference to "true white." Select from
Auto, Auto_H, Auto_L, Preset, or Manual.
Auto Exposure: Set Brightness, Shutter Mode, Digital Slow Shutter, Shutter Speed, AGC Gain, and BLC Mode.
1. Brightness: Select from 0 (darkest) to 20 (brightest).
2. Shutter Mode: Set the amount of light allowed in the video manually or automatically.
3. Digital Slow Shutter: Recommended in low light conditions. Turn On (2x, 3x, 4x) or Off.
4. Shutter Speed: Select the
speed at which the camera's
shutter will operate—1/30, 1/60,
or 1/120.
5. AGC Gain: Maximum light
gain settings in low light
conditions. Select from 0
(least light) to 20 (most light).
6. BLC (Back Light
Compensation) Mode: This
setup allows the camera to
process an image that is
harshly silhouetted against a
bright light source. Turn On
or Off.
7. Select Apply to save changes
