WEBVIEWER*
D i s p l a y S c r e e n > S e t u p > V i d e o & A u d i o > A u d i o
•
Connect speaker/microphone wires (not included) to your camera and to a monitoring device (ex.: PC
computer).
1. On the Display Screen in your Webviewer, go to Setup, Video & Audio, and finally, Audio. Adjust
settings to your preference.
a) Audio Input: Set Gain (0-5).
b) Audio Output: Set Buffering Time & Volume (0-5).
c) Network Transfer: Select Transfer Audio regardless of video.
d) Select Apply to save changes.
2. On the Display Screen, change Audio (in the bottom left corner) from OFF to 1. This will enable you to
hear external audio.
3. To transfer audio to the camera, select the 'headset' button beneath Audio.
