Digital Watchdog MEGApix DWC-MV421D User Manual page 41

WEBVIEWER*
D i s p l a y S c r e e n > S e t u p > N e t w o r k > D y n a m i c D N S
If you do not use a public IP address, DDNS provides you to connect on WAN. DDNS allows you to connect to the
MEGAPIX camera with a URL address instead of an IP address. DDNS automatically redirects traffic to your IP
address every time it changes.
1. To use DDNS, select the Use DDNS checkbox.
2. Select one of the DDNS System Names from the drop down list.
3. Enter Username & Password. The Username & Password must be registered at the DDNS site.
4. Enter Host Name.
5. Reboot your system to apply the changes to your camera. To Reboot, select Apply. A dialogue box will appear,
select OK. System will automatically restart and may take up to 20 seconds to reboot.
1
2
4
5
3
41
