Transmitter management

Code Transmitter
fi g
35
Press Tx'er
Button!
fi g 36
fi g 37
12 I 2
OSC PED LGT VAC
fi g 38
MENU 1.1
Code
fi g 39
GDO-10V1 Toro
24
MENU 1
PRESS
PRESS
List
PR E S S
Press Tx'er
Again View
PRESS
B B SMITH
D
PRESS
PRESS
TX# 14
® Owner Installation Instructions
The GDO-10 provides a transmitter listing facility which
enables the user to fi nd a transmitter location within
memory. Once located a stored transmitter can be
replaced, deleted, edited, copied or, if the location is
empty, a new transmitter can be coded.
Method 1 - Go To The Start Of The List
Step 1. Accessing The List Menu
1. Press NEXT to navigate to the Menu 1 (Fig. 35).
2. Press SET to enter the transmitter edit procedure.
3. Press NEXT to enter transmitter list and edit mode.
Method 2 - Use Transmitter To Go Direct To
List
Step 1. Accessing The List Menu
1. Press NEXT to navigate to the Menu 1 (Fig. 35).
2. Press SET to enter the transmitter edit procedure.
3. Press transmitter once (Fig. 36).
4. Press NEXT to view transmitter parameters (Fig. 37).
This method is used for quick navigation if the
transmitter is available.
NOTE: "VIEW>" will not be shown if the transmitter is
not stored.
Once the list is displayed it can be sorted by stored
number, ID Label or Serial Number. Use NEXT or PREV
button to select sorting method.
NOTE: When sorting by ID label or S/N, only stored
transmitters locations are displayed.
Step 2. Navigating The List
1. Press OPEN or CLOSE buttons to navigate through
list (Fig. 38).
NOTE: Holding a button down will step through the
list faster.
2. Press SET to display menu of available functions.
Selecting An Operation
Press NEXT or PREV to cycle through four menu
options (Fig. 39-42). Press STOP to return to the list.
Press SET to execute the menu's operation.
Code Operation (location empty)
If the code operation is selected on an empty
transmitter location, the BASIC CODE TRANSMITTER
PROCEDURE will be initiated with the transmitter
being saved in the selected location. This is useful
when managing transmitters using a scheme which ties
the store location to the transmitter's owner.
