AD9643/AD9613/AD6649/AD6643 User Guide
Item Qty Reference Designator
73 1 C531
74 1 E203, E206
75 1 J403, J404, J502, J503, J505
76 1 L201, L202
77 1 L403, L404, L405, L406, L409, L410, L411, L412
78 L507
1
79 1 R102
80 1 R104, R107, R108, R517, R627, R629
81 1 R105, R301, D55R321, R437, R438, R520, R521,
R529, R530
82 1 R106, R109, R110, R111, R112, R204, R216,
R218, R221, R311, R312, R331, R332, R403,
R404, R406, R407, R410, R411, R414, R415,
R508, R533, R534, R538, R541, R542, R608,
R630, R631, R632
83 1 R215, R220
84 1 R405, R408
85 1 R412, R426, R443, R444
86 1 R433, R446
87 1 R507
88 1 R512, R633, R634, R635, R636, R637, R638,
R639, R640, R641, R642, R643, R644, R645,
R646, R647, R648, R649, R650
89 1 R543
90 1 T301, T305, T502
91 1 T401, T402
92 1 U401
93 1 U501
94 1 U603
95 1 Y501
1 Do not install.
Description
12 pF capacitor ceramic C0G 0402
100 MHZ inductor ferrite bead
Connector-PCB SMA ST edge mount
2.2 µH inductor SM
120 nH inductor SM
3.9 nH inductor SM
2.0 kΩ resistor film SMD 0402
10 kΩ resistor PREC thick film chip R0402
49.9 Ω resistor PREC thick film chip R0402
0 Ω resistor film SMD 0402
TBD_R0603
130 Ω resistor PREC thick film chip R0402
150 Ω resistor ultra-PREC ultrareliability
MF chip
1 kΩ resistor ultra-PREC ultrareliability
MF chip
TBD_R0402
100 Ω resistor PREC thick film chip R0201
100 Ω resistor film SMD 0402
XFMR RF
XFMR RF
IC Analog Devices ADL5202
IC Analog Devices AD9523-1
IC Analog Devices CMOS, quad SPDT
switches
60 MHz to 800 MHZ IC oscillator voltage
controlled oscillator
Rev. A | Page 25 of 26
UG-293
Manufacturer/Part No.
Murata GRM1555C1H120JZ01D
Panasonic EXC-ML20A390U
Samtec SMA-J-P-X-ST-EM1
Toko FDV0630-2R2M
Panasonic ELJ-RER12JF3
Toko LL1005-FN3N9K
Multicomp CR10B202JT
Panasonic ERJ-2RKF1002X
Panasonic ERJ-2RKF49R9X
Panasonic ERJ-2GE0R00X
Panasonic ERJ-2RKF1300X
Susumu RG1005P-151-B-T5
Susumu RG1005P-102-B-T5
Panasonic ERJ-1GEF1000C
Venkel CR0402-16W-1000FPT
Mini-Circuits ADT1-1WT+
Mini-Circuits TC3-1T+
Analog Devices ADL5202
Analog Devices AD9523-1BCPZ
Analog Devices ADG734BRUZ
Epson Toyocom TCO-2111
