Entering Residents' Codes And Tel - Mircom ADC Series Installation, Programming, And Troubleshooting Manual

7-digit telephone number to form up to 11 digits. Factory defaults for 10 Prefixes are 0905.
Unused prefix digit(s) can be blanked out by pressing the "#" key.
After entering the desired Code and Prefix #, the next screen should be...
Press # to store or * to abort entry. Repeat this process to edit or to assign a new prefix number.
To exit to Normal Mode, enter *000 while at PROGRAM MODE menu.
ENTERING RESIDENTS' CODES AND TELEPHONE NUMBERS:
To enter codes and telephone numbers, scroll through until you reach the feature as shown below.
Press # to access the feature. The screen should change according to the digit length chosen. Below are the possible
screen applications.
7 digits telephone # (default)
Code Telephone
____ ___ - ____
Enter up to 7-digit
telephone number.
Enter: 000x for one (1) digit dial code
Enter: 00xx for two (2) digit dial code
Enter: 0xxx for three (3) digit dial code
Enter: xxxx for four (4) digit dial code
0 = ZERO x = RESIDENT/TENANT DIAL CODE (numeric 0 to 9)
For example: To call a resident/tenant with two digits dial codes, simply enter xx.
Press # key to blank-out unused telephone digits. This feature (to be able to blank-out any desired digit) is
particularly useful when requiring a shorter number of digits to be dialled out through a compatible private DTMF type
telephone system. When you make a mistake and wish to reenter the code and tel. #, press *.
After entering the Code and Telephone number, the next typical screen should display...
For 7-digits
#=Store, *=Abort
xxxx xxx - xxxx
Press # to Store or * to abort entry. Repeat this process until all dial codes and telephone numbers are entered. Press
* to return to PROGRAM MODE menu. To quit, enter *000 while at PROGRAM MODE menu to return to NORMAL
MODE.
Entering up to 11-digit Residents' telephone numbers: Special Feature
As mentioned previously, the user must set the Code and Prefix number when 9 to 11-digit telephone numbers are
required. The following example will illustrate how the unit should be programmed.
Example: Ten digits telephone number is required.
MIRCOM TECHNOLOGIES LIMITED, ADC Series: Autodialer Telephone Access Systems
#=Store *=Abort
( x ) x x x x
To Enter Resident
Codes - Press #
8 digits telephone #
Code Telephone
____ ___ - ____
Enter up to 8-digit
telephone number.
For 8-digits
#=Store, *=Abort
xxxx xxx - xxxx
11 digits telephone #
Code Telephone
____ ___ - ____
The first digit is used
for prefix CODE number
assigned. The remaining
digits are used for standard
7-digits tel. number.
For 11-digits
#=Store, *=Abort
xxxx xxx - xxxx
Page 38
