Working with Presets
The four user presets of the
stage during your show or event.
1/ Press the PRESET button, then press one of the four first Input
Selection section buttons to choose which memory (1-4) you wish to
use. The preset will be displayed on your preview screen.
2/ Once you have selected your preset, simply press the TAKE
button to view the result on your main screen.
Working with Audio
The Smart Vu allows to work with up to 5 stereo inputs, 1 auxilary
input, all accessible via the Audio menu of the
can be affected to one or both of the 2 independant symetrical/
asymetrical outputs of the device.
Audio configuration
To configure audio settings of the
into the device, and navigate to the Audio menu.
1/ Choose the audio mode, Break Away or Top Layer Follow, which
you wish the audio to work in.
* NOTE * : the Break Away mode will air the selected audio source,
while the Top Layer Follow mode will air audio from the toptmost
active layer of the Smart
2/ Select Source Settings from the Audio menu to select the audio
source you wish to work with, then set levels and left/right balance
for each input.
3/ Select Auxiliary Settings to determine level and balance of the
auxilary input.
4/ Select the Main Output menu to determine main audio output
level, balance and delay settings, or to mute main audio output.
5/ Select Audio Prelist, from the Audio menu, to determine pre-
listen audio output level, balance and delay settings, for each audio
input, or to mute Prelist audio output.
6/ Select Delay Mode, to determine how the
audio delay. Select Auto Adjust to let the
audio output delay. Select Manual Adjust to determine audio delay
manualy.
*NOTE* : selecting Manual Adjust will give access to audio delay
value (in milliseconds) of the main audio output menus.
Smart Vu can be called back at any
Smart
Smart Vu, plug all audio inputs
Vu.
Smart Vu
Smart Vu
Vu, and which
deals with
determine
