4-2. THE Smart Vu MENU
Menu navigation
To access the Smart Vu
the menu which will appear on the VFD screen (1), turn the scroll knob (4) left or right to the desired menu
item. When you have reached the desired menu item, press the ENTER button in the control section (3) to
access that menu function. Pressing the ENTER button when a selection has been made sets the value to
that selection in the
exit sub-menus and return to the main menu.
* IMPORTANT * : simply selecting a menu item will not set it to that value. Be sure to press the ENTER button
when parametering the menu items.
Simply selecting a menu item will not set it to that value. Be sure to press the ENTER
!
button when parametering the menu items or to push the scroll knob.
Home menu
Pressing the [MENU]
to the following items on the menu VFD screen:
- INPUT: select to configure the 7 individual input types and resolutions.
- MAIN OUT: select to set the output types and resolutions of the Main output.
- PREVIEW OUT: in Mixer mode, select to set the output types and resolutions of the Preview output.
- PRESET: select to store and use presets.
- IMAGE: select to change source image settings of an input.
- KEYING/TITLING: select to access keying and titling controls and parameters.
- LAYER: select to adjust layer size, position, border, transparency or transitions.
- AUDIO: select to access all audio input and output parameters.
- CONTROL: select to access device software information, LAN settings, reset factory settings, amongst
other user oriented functions.
26
menu, press the EXIT/MENU button in the control section (2). To highlight items in
Smart Vu memory. When all settings have been made, press the EXIT/MENU button to
button in the menu section of the Smart Vu, will display and give you access
