Software overview
The RCS software for your
(1) allows you to navigate through the equivalent of the
SmartVu Menu"). The green window of the RCS (2) represents your Preview window, and can be used to
parameter sources, frames, layers and logos directly by clicking on the corresponding button, then navigating
through the different available tabs. The red window of the RCS (3) represents your Main window, and can
also be used much like the front panel of the
by clicking on one of the four available Preset icons (4) and setting up your preset in the Preview window.
Clear unwanted steps with the clear button (5), reload a fresh copy of your screen via the Reload Main button
(6), make smooth takes directly with your mouse or trackpad with the virtual T-bar (7). The Take button (9) will
allow you to view any changes made to your preview screen on your main screen, and Analog Way engineers
have even implemented a Stepback button (8) to quickly move back to your previous setup in the case of a
manipulation error. The status section (10) allows for easy monitoring of the connection status.
4
5
6
The RCS software for your
menu section. It allows you to quickly access all of the
easily edit your settings directly from your laptop or PC.
Before starting with the RCS software, you must establish a connection from your laptop to the
wish to run.
42
Smart Vu is composed of several easily identified sections. The tabs menu
Smart
1
2
10
Smart Vu can be viewed as the software version of the
Smart Vu front panel menu items (see also "The
Vu. Create user presets directly in the RCS main window,
Smart Vu functions via a single page interface, and
3
Smart Vu front panel
Smart Vu
7
8
9
you
