Communication specifications

• COMMUNICATION PORTS:
REMOTE RS232
Connector: DB 9 female
Level: RS232.
Data Rate: 9600 Bauds, 8 data bits, 1 stop bit, no parity bit,
no flow control for normal. DTR & RTS needed for
upgrade.
• LAN:
Connector : RJ45
Protocol: TCP (Transmission Control Protocol) or UDP
(User Datagram Protocol).
Ethernet: Base 10/100

Environmental specifications

PHYSICAL
Dimensions: W 482 x D 350 x H 45 mm
19"W x 13.8"D x 1.8"H.
(Compatible with a Standard 19" rack, Height = 1 U).
Weight: 4.3 kg / 9.5 lbs.
ENVIRONMENTAL
Cooling air flow from right side to left side
Maximum ambient operating temperature: < 40 °C ( < 104°F).
Operating temperature:
Storage temperature:
Operating humidity:
Input voltage range:
Typical consumption:
CERTIFICATIONS
CE Compliancy: test following
- EN 55022: 2006 / A1: 2007,
- EN 55024: 1998 / A1: 2001 / A2: 2003,
- EN 61000-3-2: 2006
- EN 61000-3-3: 1995 / A1: 2001 / A2: 2005,
Safety : test following:
Power supply: IEC/EN/UL/CSA 60950-1, internal, autoswitchable
Mechanical (in carton): Vibration: IEC60068-2-64
Free fall: IEC60068-2-32, RoHS, WEEE
0 to 40 °C / +32 ° to +104 °F
-25 to 85 °C / -13° to +185 °F
10 to 80% (non condensing)
100-240 VAC, 50/60 Hz
90 W (with option)
- IEC 60950-1: 2005
- UL 60950-1: 2007
- CAN/CSA-C22.2 NO. 60950-1
15
