CONNECTING THE PLS300
3-1. CONNECTING THE Smart Vu
The Smart Vu can be set up with up to 7 different sources, and will drive up to 1 digital DVI-D source, 2 SD-
SDI sources and 4 analog computer/video sources simultaneously. The versatility of the
for almost any event configuration and cater for all your projection needs.
The intuitive rear panel of the
example of a typical
18
Smart Vu will let you set up for the first time quickly and easily. Here is an
Smart Vu setup.
Smart Vu will allow
