Status Icons

The following table identifies the icons that can appear in the system status bar.
Icon
Network
Status
System
Overheating
LifeSize Express 200 Installation Guide
Condition
Indicates that the communication subsystem is initializing. If this icon
reappears after the system has booted, a problem has occurred. Reboot
the system.
Indicates that the system is initializing. When the system is initializing,
functionality on the main screen is disabled and no entries appear in the
REDIAL list. This icon also appears when a new device is connected to
the system after the system boots and disappears when the device is
ready. If the icon persists, a problem has occurred and rebooting the
system is necessary.
Indicates that the connected phone has been detected and the phone is
initializing. If the icon persists, a problem has occurred and rebooting the
system is necessary.
Indicates that the system does not have an active microphone. Check the
device's connections and then check the option you selected for the
Active Microphone preference.
Identifies the network status, as follows:
connected (green indicator)
in progress (yellow indicator)
disconnected (red indicator)
This yellow indicator warns you when the system temperature is
above normal operating temperature. The codec adjusts fan speed
automatically to cool itself.
This red indicator warns that the system is overheated and
approaching the maximum allowed operating temperature and will
automatically reboot after reaching it.
Warning: Temperatures that require the codec to reboot can permanently
damage codec components. Ensure the room that houses the codec is
properly ventilated and temperature controlled.
