Warning: Do not place anything on top of or adjacent to the codec that can obstruct
air flow around the unit or generate heat. Doing so can cause the system to overheat
and reboot. Prolonged overheating can result in damage to the codec. Ensure the room
that houses the codec is properly ventilated and temperature controlled.
Refer to the LifeSize quick reference card included with your system for a visual depiction of
the proper setup. The numbers that appear on the quick reference card correspond to the
following steps:
1. Open the battery compartment on the back side of the remote control.
a. Before inserting the batteries, stretch each of the two straps across the outer battery
slot closest to it.
b. Insert the two outer batteries, negative end (-) first against the spring, then press the
positive (+) end into place, trapping the cloth straps beneath the batteries.
c. Lay the longer cloth strap over both batteries and insert the center battery's negative
end against the spring first to trap the longer cloth strap beneath it. Then press the
positive end of the battery into place.
d. Lay the ends of the cloth straps over the center battery and install the cover.
2. To connect to a LifeSize Camera (2a) or LifeSize Focus (2b), insert the camera cable
into the port on the rear side of the camera and plug the opposite end into the port
marked with the camera symbol
3. Insert a video display cable into the port on the rear of your display and the opposite end
into the port marked with the display 1 symbol
the display power cord into a power outlet on the wall.
Note: If you plan to use external speakers that are not built into the display, connect
the speakers to the port marked with the line out symbol
To connect a second display, insert a video display cable into the port on the rear of your
display and the opposite end into the port marked with the display 2 symbol
back of the codec (3b). Insert the display power cord into a power outlet on the wall. By
default, the second display is blank. After you complete the initial configuration, refer to
"Configuring a Second Display" on page 16 to complete this process.
4. Insert the network cable into the network port marked with the LAN symbol
back of the codec. Insert the opposite end of the network cable into a network port on
the wall.
LifeSize Express 200 Installation Guide
on the back of the codec.
on the back of the codec (3a). Insert
on the back of the codec.
on the
on the
13
