— An iScan Duo icon should appear on your PC's desktop. The iScan Duo looks like a mass
storage device to your PC.
— Double click on the iScan Duo icon. You should see a file with a '.abt' extension.
Select that file and delete it.
— Copy the new '.abt' file into the iScan Duo icon.
— After the file has been copied, the iScan Duo will automatically update its firmware
and indicate progress on the Front Panel Display.
IMPORTANT: Make sure the file you are copying to the iScan Duo has a '.abt' extension.
•

Serial Port Rate

The serial port is used by automation system controllers to control the iScan Duo. The serial port
baud rate defaults to 19200 bps, but can be changed using the navigation
the remote control.
The supported baud rates are:
4800 bps (4.8K)
9600 bps (9.6K)
14400 bps (14.4K)
19200 bps (19.2K) - default
38400 bps (38.4K)
115200 bps (115.2K)

Wizard Launch

The iScan Duo features two 'Wizards' to guide you through setup of your display, A/V receivers and
input devices.
•

Display Wizard

The Display Wizard assists setup of your display and audio.
Using Display Wizard, you can:
If you don't want to change anything, press
Changing the Display Name:
Press ENTER or
Use this on-screen keyboard to rename your display with the navigation remote buttons.
When you are finished, highlight Finish then press OK to accept the new name. If you
want to exit the keyboard screen with no changes, highlight Cancel, then press OK.
Changing the Output Format:
Press ENTER or
This takes you to the Output Format menu. Refer to the Output Format section.
Changing the Audio Output:
Press ENTER or
This takes you to the Audio Output menu. Refer to the Audio Output section.
23
1. Name your display.
2. Select an output video format.
3. Select an output connector for audio.
u
if you want to change the name of your display.
u if you want to change the output format.
u
if you want to change the audio output.
t
to Exit the Wizard.
p or q buttons on
