Crestron TPMC-8L
Operations & Installation Guide – DOC. 6594B
Isys i/O™ 8.4" Touchpanel Media Center
A balanced line output allows for connection to Adagio
distribution systems using CAT5 or conventional wiring, allowing streaming audio
content playing on the TPMC-8L to be shared with listeners throughout the home or
office. (The line level output carries precisely the same signal as the built-in stereo
speakers.)
Intercom and Telephone
Built-in IP intercom capability facilitates direct panel-to-panel intercom and
monitoring right over the LAN without requiring any additional AV wiring. New
Crestron SIP phone allows 2-way communication between touchpanels as well as
with traditional PSTN (public switched telephone network) telephones and other
SIP/VoIP phones.
NOTE: SIP Phone requires a high speed LAN and/or broadband connection and a
connection to a SIP server or SIP-based Internet phone (VoIP) service provider.
Biometric Scanner
The built-in fingerprint scanner unleashes a whole new level of convenience and
security, allowing individual users to be identified instantly and logged on
automatically. With just the touch of a fingertip, each user can be presented with a
unique graphical interface with its own set of preferences, access privileges and even
its own look through the use of touchpanel "skins".
Pushbutton Options
The TPMC-8L features a faceplate containing 16 programmable "hard key"
pushbuttons, elegantly trimmed by illuminated button dividers. Integral to the
faceplate, the pushbuttons are positioned along the left and right edges of the
touchscreen, making it possible to align dynamically changing text and graphics
onscreen beside the pushbuttons to support context-sensitive menu functions such as
digital media titles, channels or lighting presets. Custom engraving of the buttons is
available, with a choice of solid or backlit text. A plain, no-button faceplate is also
included, allowing a very clean appearance with no pushbuttons.
Light Sensor
A light sensor is built into the TPMC-8L to automatically adjust the display
brightness and button backlight for optimal legibility under varying light conditions.
High Speed Connectivity
High speed Ethernet is standard on the TPMC-8L, providing for easy network
integration and seamless communications with Crestron control systems, computers
and digital media servers. Two USB 2.0 ports are also included on the rear panel to
support a mouse and keyboard and external storage devices.
Versatile Flush Mount Design
The TPMC-8L is designed for easy flush mount installation in a wall, lectern or
similar flat surface. A variety of mounting accessories is offered including optional
back box and 19-inch rack mount kit.
Isys i/O™ 8.4" Touchpanel Media Center: TPMC-8L • 3
®
or other multi-room audio
