from standby mode. When the touchpanel is reactivated, the last screen to be
displayed reappears.
NOTE: The pushbuttons will still function when the touchpanel is in standby mode
but will not cause it to awaken from standby. You must touch the screen to reactivate
the touchpanel.
Ethernet Status Details
The Ethernet Status section of the setup menu has an indicator to show when the
TPMC-8L is connected via its LAN port. IP and Mac addresses are also shown.
Save & Reboot Details
To save any changes and reboot the touchpanel, touch Save & Reboot, located in the
lower right section of the setup menu.
Exit Details
Touch Exit to leave the setup menu and return to the project. If no project has been
loaded, the touchpanel will display an error message and return to the setup menu.

Mounting Options

The TPMC-8L touchpanel installs simply and cleanly into existing or newly
constructed walls with an assortment of pre- and post-construction mounting options.
All mounting options are provided separately from the actual touchpanel. Refer to
the following table for a complete list of mounting options and respective Installation
Guides for this touchpanel.
Mounting Options for the TPMC-8L
PRE-CONSTRUCTION* POST-CONSTRUCTION**
OPTION
Back Box Kit
Pre-Construction Mount
Kit
Mud Mount Kit
(accessory)
Trim Mount Kit
(accessory)
-
-
* Pre-construction refers to framed walls prior to hanging drywall.
** Post-construction refers to framed walls with drywall hung.
NOTE: There is also a rack mount kit (RMK-8L) available for the TPMC-8L. Refer
to the latest version of the RMK-8L Installation Guide (Doc. 6596).
If the BB-8L or PMK-8L are to be used and a touchpanel is not available, the
installer can either leave the hole in the mounting surface open (if permitted by local
building codes) or attach the cover plate supplied with the mounting kit.
Isys i/O™ 8.4" Touchpanel Media Center: TPMC-8L • 39
MODEL NUMBER
OPTION
-
-
-
-
Wall Mount Kit – Mud
Wall Mount Kit – Trim
DOCUMENT
NUMBER
BB-8L 6589
PMK-8L 6590
MMK-8L 6591
TMK-8L 6592
WMKM-8L 6591
WMKT-8L 6592
