Crestron TPMC-8L
Operations & Installation Guide – DOC. 6594B
Isys i/O™ 8.4" Touchpanel Media Center
"Message Popup Configuration" Window
There are three types of Network popup messages. Following are definitions of each
message type:
•
Connected: A green popup message appears when the panel is
connected to the control system.
•
Checking Connection: A yellow popup message appears when the
panel is experiencing network issues.
•
Disconnected, Trying to Reconnect...: A red popup message appears
when the panel loses connection with the control system.
A control for popup message Translucence is also provided. Translucence ranges
from 25% to 100%, with a default value of 90%.
The Default button restores the original Screen Position and Translucence settings,
as well as enabling display of Network messages. A Test Message button lets you
see the changes to popup message position and translucence. Touch Close to close
the popup window.
NOTE: The default value for Screen Position is Lower Left.
Isys i/O™ 8.4" Touchpanel Media Center: TPMC-8L • 33
