Operation

54 • Isys i/O™ 8.4" Touchpanel Media Center: TPMC-8L

Power Modes

The TPMC-8L has three power modes: On, Standby and Off. Refer to the following
table for details.
TPMC-8L Power Modes
POWER MODE
On
Standby
Off
* Standby mode can also be initiated using a reserve join number in VT Pro-e and the Device Extender
function in SIMPL Windows. For details, refer to the respective help files in these programs.
NOTE: When power is first applied to the touchpanel, the BIOS screen (white text
on black background) will be upside down. This will only occur during boot up.
Crestron TPMC-8L
DETAILS
Normal operating mode.
Backlight is turned off but processor is still
on and pushbuttons are still functional.
Initiated with Standby function from the
setup menu.* Touch the screen to
reactivate the TPMC-8L from standby
mode.
All power is off. The TPMC-8L is off when
no power is applied to the 24 V DC input.
