Crestron TPMC-8L
Operations & Installation Guide – DOC. 6594B
Isys i/O™ 8.4" Touchpanel Media Center
NOTE: Select Exit Setup Mode to exit the setup menu.
TPMC-8L Setup Menu
NOTE: Another way to enter the setup menu (after a project has been loaded) is to
touch the screen during boot up when you see the "Preparing to Load Project"
message. Maintain touch until after the countdown, when the message will change to
"Loading Setup Screen".
The setup menu provides access to all basic functions and parameters. It is divided
into Setup, Ethernet, Screen Brightness, Light Sensor, Hardkey Backlight, Standby
and Ethernet Status sections. There are also buttons for Install, Save & Reboot and
Exit.
NOTE: To allow the touchpanel to upload projects, standby is disabled until
approximately five minutes after the project is loaded.
NOTE: The Install button is reserved for future applications.
To exit the setup menu and return to the program, touch Exit, located at the bottom
of the setup menu. To save any changes and reboot the touchpanel, touch Save &
Reboot, located at the bottom of the setup menu.
Setup Menu Details
The setup menu allows configuration of the touchpanel's settings for security, touch
screen calibration, runtime project, audio, embedded applications, biometrics, hard
button programming and diagnostics. The setup menu also has a button that will
toggle the on-screen keyboard on and off.
Isys i/O™ 8.4" Touchpanel Media Center: TPMC-8L • 13
