SPARC Enterprise M5000 Server With Dual-power Feed Connection
FIGURE 2-4
#2
#3
#1
2.2.1.2
Grounding
The system is shipped with grounding-type (three-wire) power cords. Always
connect the cords into grounded power outlets. Contact your facilities manager or a
qualified electrician to determine what type of power is supplied to your building.
No additional earth grounding is necessary but it may be added if desired.
#0
PSU#0 PSU#1 PSU#2 PSU#3
Circuit
breaker
Circuit
breaker
Chapter 2
Preparing to Install the Server
2-7
